Handheld Rf Spectrum Analyzer
RF Explorer is a Radio Frequency Spectrum Analyzer, Signal Meter, and Signal Detector that detects frequencies in the 15 MHz–2700 MHz range. This affordable handheld scanner detects the distance, strength and direction of existing wifi & cell signals making it an effective tool for wi-fi & cell phone signal booster installations. Below is a link to RF Explorer’s user manual — updated through firmware version v1.11. The manufacturer is constantly adding new features to RF Explorer, therefore newer firmware versions may have additions and changes not yet included in the User Manual. RF Explorer - there is a wireless world to explore! RF Explorer Quick Start instructions: RF Explorer Spectrum Analyzer User Guide (English). RF Explorer Pro Audio Edition User Manual page 12 ANALYZER SCREEN IN ADVANCED MODE Alternatively, there is a simpler way to increase and decrease frequency span while keeping the center frequency. As this is a common workflow, the RF Explorer Spectrum Analyzer screen enables the Return key to switch between standard.
RF Explorer User Manual page 8 Spectrum Analyzer mode - Main Screen Upon start, RF Explorer goes to Spectrum Analyzer mode automatically. The X axis represents frequency in MHZ and Y axis display actual received power in dBm or dBuV (selectable). In this example above, the frequency span goes from 2390 MHz to 2450 MHz (that is a 60MHz. RF Explorer User Manual page 9 Spectrum Analyzer mode - Main Screen Upon start, RF Explorer goes to Spectrum Analyzer mode automatically. The X axis represents frequency in MHZ and Y axis display actual received power in dBm or dBuV (selectable). WiFi Surveyor turns data collected from RF Explorer spectrum analyzers into graphical charts and displays in real time, enabling users to more readily visualize the RF environment, monitor RF signals, troubleshoot RF issues, and detect sources of RF interference.
The RF Explorer® Pro Audio Edition is an all-new portable RF spectrum analyzer designed specifically for use with wireless microphones and in-ear monitor systems.
Available exclusively through RF Venue dealers and distributors, the RF Explorer Pro Audio Edition is the perfect addition to any audio pro's toolkit. With a 50 ohm BNC input connector designed to interface directly with wireless audio systems and accessories such as remote antennas, antenna distribution systems, or RF over fiber modules, the Pro Audio Edition spectrum analyzer is the ideal tool to troubleshoot, optimize, and commission your next wireless system.
The Stryker NAV3i Platform has the performance specifications and accessories you expect from a top-of-the- line surgical navigation system.
Compatible with RF Venue's Vantage Mac OSX software as well as multiple PC applications, the Pro Audio Edition comes packed with a range of new features.
- 15-2700 MHz Wideband scanning range
- Configurable Low Noise Amplifier
- Save / Load Presets for fast setup and recall
- Configurable Input Attenuator
- One-Click WiFi Analyzer mode displays 2.4 GHz channels
- 16 hour lithium-ion rechargeable battery
- -120 dB Sensitivity and auto-configurable resolution bandwidth (RBW)
The RF Explorer Pro Audio Edition’s easy-to use interface takes the complexity out of RF spectrum analysis for audio, empowering audio engineers and wireless audio system managers to better monitor, manage, and configure their systems in today's ever-changing RF spectrum landscape.
Spectrum Analyzers For Sale
Carrying case, UHF band articulating whip antenna, and shielded USB cable included
Rf Explorer Spectrum Analyzer User Manual Pdf
Software is sold separately.
